Primerjava strojev
Preglejte tehnične podatke izbranih strojev drug ob drugem. Spremenite izvedbo vsakega stolpca s spustnim menijem in vklopite »Prikažite samo razlike«, če Vas zanimajo le točke, kjer se stroji razlikujejo.
TOTUS · Primerjava strojev
FW classic · FW classic · FW classic · FW classic — 9. 10. 2026 · cene brez DDV · www.totus.si
27 od 27 postavk po Ceniku 2026
| Stroj | FW classic | FW classic | FW classic | FW classic | |
|---|---|---|---|---|---|
| Izvedba | FW 850 classic | FW 850 classic | FW 850 classic | FW 850 classic | |
| Osnovna cena | Na zahtevo | Na zahtevo | Na zahtevo | Na zahtevo | |
 | | | | ||
FelderIzvedba 1  FW classicNa zahtevo | FelderIzvedba 2 FW classicNa zahtevo | FelderIzvedba 3 FW classicNa zahtevo | FelderIzvedba 4 FW classicNa zahtevo | ||
| POS | Oprema / specifikacija | FW 850 classic | FW 850 classic | FW 850 classic | FW 850 classic |
| Tehnične specifikacije (Cenik 2026)· S = serijsko · O = opcija (doplačilo) · — = ni na voljo Oznake v nazivih: ! = ni združljivo z · # = le skupaj z · / = ali · + = in | |||||
| Električna oprema | |||||
| 001 | 3x 400 V motor voltage, 50 /60 Hz motor frequency | S | S | S | S |
| 002 | 3x 230 V motor voltage, 50 /60 Hz motor frequency, autotransformer input 208 / 240 / 400 / 415 / 440 / 480 volts | O | O | O | O |
| 008 | 7.5 HP (5.5 kW) sanding belt motor for sanding unit | S | S | S | S |
| Automatic sanding-belt brake | S | S | S | S | |
| Brusilna enota in brusilna blazina | |||||
| Combination sanding unit KA (contact roller and sanding pad), hardness of the contact roller KA 85° Shore, mode of operation can be selected from the control panel | S | S | S | S | |
| 300 | Electro-pneumatic sanding cushion EP | S | S | S | S |
| Grinding width 850 mm | S | S | S | S | |
| Grinding height 3-155 mm | S | S | S | S | |
| Sanding belt is oscillated electro-pneumatically | S | S | S | S | |
| Electronic run-off protection for the sanding belt | S | S | S | S | |
| mechanical grinding belt tension | S | S | S | S | |
| Abrasive belt 860 x 1400 mm (width x length) | S | S | S | S | |
| Podajalna miza | |||||
| Electronic height adjustment of the feed table in 0.1 mm incremental steps from the control panel | S | S | S | S | |
| Digital display shows the height of the feeder table | S | S | S | S | |
| Feed speed can be selected from the control panel, 50Hz =4 / 8 m /min, 60Hz =4.8 / 9.6 m /min, cutting speed 50Hz =12.5m /sec, 60Hz =15m /sec | S | S | S | S | |
| Mechanical vibration-absorbing rubber pressure rolls | S | S | S | S | |
| handguard flap | S | S | S | S | |
| Pomembni dodatki | |||||
| 101 | 14.3.0915 - Wide belt sanding belts 860 x 1400 mm, K=60 (12 pieces) | O | O | O | O |
| 102 | 14.3.0925 - Wide belt sanding belts 860 x 1400 mm, K=80 (12 pieces) | O | O | O | O |
| 103 | 14.3.0935 - Wide belt sanding belts 860 x 1400 mm, K=100 (12 pieces) | O | O | O | O |
| 104 | 14.3.0945 - Wide belt sanding belts 860 x 1400 mm, K=120 (12 pieces) | O | O | O | O |
| 105 | 14.3.0955 - Wide belt sanding belts 860 x 1400 mm, K=150 (12 pieces) | O | O | O | O |
| 106 | 14.3.0965 - Wide belt sanding belts 860 x 1400 mm, K=180 (12 pieces) | O | O | O | O |
| 107 | 14.3.0975 - Wide belt sanding belt set 860 x 1400 K=80, K=120 and K=150 (4 pieces each) | O | O | O | O |
| Splošno | |||||
| Machine packing dimensions in mm (length x width) | 1200 x 1160 x 1700 | 1200 x 1160 x 1700 | 1200 x 1160 x 1700 | 1200 x 1160 x 1700 | |
| Priklop odsesovanja Ø, mm | 1x 120 | 1x 120 | 1x 120 | 1x 120 | |
| Teža (serijska konfiguracija), kg | 420 | 420 | 420 | 420 | |
